RE Crossed Roller Bearings

Drawing

Datasheet

Bearing No.	Dimensions								Mass
Bearing No.	d	D	dp	BB1	Greasing hole		ds	Dh
–	mm	mm	mm	mm	a	b	mm	mm	kg
RE 2008	20	36	29	8	2	0.8	23.5	30.5	0.04
RE 2508	25	41	34	8	2	0.8	28.5	35.5	0.05
RE 3010	30	55	43.5	10	2.5	1	37	47	0.12
RE 3510	35	60	48.5	10	2.5	1	41	51.5	0.13
RE 4010	40	65	53.5	10	2.5	1	47.5	58	0.16
RE 4510	45	70	58.5	10	2.5	1	51	61.5	0.17
RE 5013	50	80	66	13	2.5	1.6	57.5	72	0.27
RE 6013	60	90	76	13	2.5	1.6	68	82	0.3
RE 7013	70	100	86	13	2.5	1.6	78	92	0.35
RE 8016	80	120	101.4	16	3	1.6	91	111	0.7
RE 9016	90	130	112	16	3	1.6	98	118	0.75
RE 10016	100	140	121.1	16	3	1.6	109	129	0.83
RE 10020	100	150	127	20	3.5	1.6	113	133	1.45
RE 11012	110	135	123.3	12	2.5	1	117	127	0.4
RE 11015	110	145	129	15	3	1.6	122	136	0.75
RE 11020	110	160	137	20	3.5	1.6	120	140	1.56
RE 12016	120	150	136	16	3	1.6	127	141	0.72
RE 12025	120	180	152	25	3.5	2	133	164	2.62
RE 13015	130	160	146	15	3	1.6	137	152	0.72
RE 13025	130	190	162	25	3.5	2	143	174	2.82
RE 14016	140	175	160	16	3	1.6	147	162	1
RE 14025	140	200	172	25	3.5	2	154	185	2.96
RE 15013	150	180	166	13	2.5	1.6	158	172	0.68
RE 15025	150	210	182	25	3.5	2	164	194	3.16
RE 15030	150	230	192	30	4.5	3	173	210	5.3
RE 16025	160	220	192	25	3.5	2	173	204	3.14
RE 17020	170	220	196.1	20	3.5	1.6	184	198	2.21
RE 18025	180	240	210	25	3.5	2	195	225	3.44
RE 19025	190	240	219	25	3.5	1.6	202	222	2.99
RE 20025	200	260	230	25	3.5	2	215	245	4
RE 20030	200	280	240	30	4.5	3	221	258	6.7
RE 20035	200	295	247.7	35	5	3	225	270	9.6
RE 22025	220	280	250.1	25	3.5	2	235	265	4.1
RE 24025	240	300	272.5	25	3.5	2	256	281	4.5
RE 25025	250	310	280.9	25	3.5	2	268	293	5
RE 25030	250	330	287.5	30	4.5	3	269	306	8.1
RE 25040	250	355	300.7	40	6	3.5	275	326	14.8
RE 30025	300	360	332	25	3.5	2	319	344	5.9
RE 30035	300	395	345	35	5	3	322	368	13.4
RE 30040	300	405	351.6	40	6	3.5	326	377	17.2
RE 35020	350	400	376.6	20	3.5	1.6	363	383	3.9
RE 40035	400	480	440.3	35	5	3	422	459	14.5
RE 40040	400	510	453.4	40	6	3.5	428	479	23.5
RE 45025	450	500	476.6	25	3.5	1.6	464	484	6.6
RE 50025	500	550	526.6	25	3.5	1.6	514	534	7.3
RE 50040	500	600	548.8	40	6	3	526	572	26
RE 50050	500	625	561.6	50	6	3.5	536	587	41.7
RE 60040	600	700	650	40	6	3	627	673	29
